TRICONEX 3623T Module

Basic Information

• Affiliated System: It is part of the Triconex safety system, which is widely used in industrial fields, especially in high-risk industries, for controlling and monitoring critical processes to ensure the safety and reliability of the system.
• Input/Output Voltage: The input voltage is 24V DC, and the output voltage is 5V DC.
• Operating Temperature Range: -40℃ to +85℃, which can adapt to various harsh industrial environments.
• Protection Class: IP67, with good dustproof and waterproof performance, can work stably in dusty, humid and other environments.
• Overall Dimensions: 100mm x 50mm x 30mm, compact in size, easy to install and integrate into various control systems.
• Weight: Approximately 150g.

Performance Features

• Communication Interface: Supports multiple communication protocols, such as Fault-Tolerant Ethernet (FTE), Modbus TCP, ENIM protocol, RS-232, RS-485, etc., enabling seamless communication and data exchange with different field devices and control systems.
• Redundant Design: Supports multiple network redundancy schemes. Through Triple Modular Redundancy (TMR) and other technologies, it ensures that the system can maintain high availability and fault tolerance when a fault occurs, avoiding system paralysis caused by a single point of failure.
• Safety Standards: Complies with the International Electrotechnical Commission standard IEC 61508 SIL 3, suitable for applications with extremely high safety performance requirements, and can effectively ensure personnel safety and normal operation of equipment.
• Diagnostic Function: Provides self-diagnosis and fault detection functions, which can monitor the operating status of the module in real-time. Once a fault is found, it can quickly locate and alarm, helping maintenance personnel solve problems in a timely manner and reduce downtime.
• Optoelectronic Isolation: Adopts optoelectronic isolation technology to isolate input and output signals from the internal circuit of the module, improving the safety and reliability of the module. It effectively prevents the impact of external interference signals on the module and also avoids damage to other equipment due to module faults.
• High Isolation Voltage: It has a point isolation voltage of 2500 VDC, which is higher than the 1500 VDC of the standard model, enhancing the stability and safety of the module in high-voltage environments.

Functions and Uses

• Control Function: Mainly used to perform tasks such as valve control and motor control, which can accurately control the operating status of field equipment to ensure the stable operation of industrial processes.
• Signal Conversion: Receives instructions from the safety controller and converts them into physical output signals, such as driving solenoid valves, relays and other safety-related equipment, to achieve effective control of industrial equipment.
• Monitoring Function: It can monitor the operating status of field equipment in real-time, collect the operating data and status information of the equipment, and transmit them to the control system, so that operators can timely understand the operating status of the equipment and make corresponding decisions.
• Replacing Traditional Switches: It can replace traditional mechanical pressure and temperature switches, improve the reliability of discrete field inputs, and retain the existing wiring and control schemes, which plays an important role in factory upgrading projects.

Application Fields

• Oil and Gas Industry: Used to monitor and control key equipment and processes in oil extraction, refining, transportation and other processes to ensure the safety and stability of the production process.
• Chemical Industry: In chemical production, it precisely controls and monitors various chemical reaction processes, material transportation, storage and other links to ensure the safety and reliability of chemical production.
• Power Industry: Used in power generation, transmission, distribution and other links of the power system, it controls and monitors generators, transformers, switchgear and other equipment to ensure the stable operation of the power system.
• Water Treatment Industry: In water treatment plants, it controls and monitors water pumps, valves, filters and other equipment to ensure the safety and reliability of water quality monitoring and treatment processes, and to ensure that the effluent quality meets the standards.
• Other Industries: It is also widely used in metal processing, food and beverage, pharmaceutical and other industries. In the production process of these industries, it controls and monitors key equipment and processes to improve production efficiency and product quality, and ensure production safety.
