Honeywell CC-TAIM01 analog input/output module

Honeywell CC-TAIM01 analog input/output module

General specification
Working voltage: Usually 24VDC, allowing for a certain range of voltage fluctuations.
Power consumption: several watts to tens of watts.
Operating temperature range: -40 ℃ to 85℃.
Storage temperature range: -55 ℃ to 125℃.

Input specification
Number of input channels: Commonly, there are 8 channels or 16 channels, which can simultaneously connect multiple analog sensors to achieve the collection of multiple analog signals.
Input signal types: Supports multiple analog input signals, including 4-20mA current signals, 0-10V voltage signals, thermocouple signals (such as K-type, J-type, T-type, etc.), and thermal resistance signals (such as Pt100, Cu50, etc.).
Input accuracy: Generally, it can reach ±0.1% or higher, ensuring that the collected analog signals have high accuracy when converted into digital signals.
Input impedance: For current input, the input impedance is usually low to ensure accurate measurement of the input current signal; For voltage input, the input impedance is relatively high to avoid excessive load effects on the input voltage signal.

Output specification
The number of output channels: Corresponding to the number of input channels, it is usually 8 channels or 16 channels, and analog signals can be output according to control requirements.
Output signal type: Generally, it is a 4-20mA current signal or a 0-10V voltage signal, which is used to control on-site actuators, such as control valves, frequency converters, etc.
Output accuracy: It is comparable to the input accuracy, usually around ±0.1%, to ensure the accuracy and stability of the output signal.
Output load capacity: When outputting current, it can provide sufficient driving capacity, generally capable of driving a load of several hundred ohms. When outputting voltage, it can provide a certain output current to meet the demands of the load.
