GE IC697BEM733: An Important Module in the 90-70 Series

Functional Features

• Communication Function: Supports Ethernet and TCP/IP protocols, equipped with an RJ45 port. It enables high-speed and stable communication between GE Series 90-70 PLCs and other devices on the network, facilitating the construction of industrial network systems and realizing data interaction and remote monitoring between devices.
• I/O Scanning and Data Transmission: As a Genius I/O scanning module, it can efficiently scan IC 66* input/output blocks and transmit data to the CPU through the backplane after each scan, ensuring that the system promptly acquires and processes input/output signals.
• Module Status Indication: Equipped with three green LEDs, which are used to indicate the module status, rack activity status, and the presence of an I/O bus terminator (IC693CPU374GP). This allows operators to quickly understand the working status of the module and promptly identify and resolve issues.
• Fault Isolation and Repair: Allows isolation and repair of faulty modules within a rack. When communication with the CPU is lost, the module will maintain the last output state, improving the stability and reliability of the system.
• Connection Method: Occupies one slot and has two connectors. One is connected to the upstream or CPU rack, and the other is used for daisy-chain connection to additional expansion racks, enabling flexible expansion of the system scale.

Technical Parameters

• Power Requirements: Generally need to comply with the power specifications of the GE Fanuc 90-70 series to ensure normal operation.
• Communication Rate: Supports Ethernet communication, and its communication rate can generally meet the data transmission requirements in industrial automation systems, enabling fast data exchange.
• Transmission Distance: Relevant data shows that the maximum transmission distance of the Genius I/O network it belongs to can reach 2300 meters. The specific transmission distance may be affected by factors such as the network environment.

Application Fields

• Manufacturing Industry: Used for equipment control and monitoring on production lines, such as automated assembly lines, robot control, and material conveying systems. It realizes the collaborative work of equipment and automated control of the production process, improving production efficiency and product quality.
• Power Industry: Can be applied to substation automation and power equipment monitoring in power systems, realizing remote monitoring and control of power equipment and ensuring the stable operation of the power system.
• Water Treatment Industry: In the automated control system of water treatment plants, it is used to monitor and control water pumps, valves, water quality monitoring equipment, etc., realizing automated management of the water treatment process and improving water treatment efficiency and water quality.
• Transportation Industry: For example, in rail transit systems such as subways and light rails, it is used to control train operation and manage station equipment, ensuring the safe and efficient operation of the transportation system.
